Bixiyaha 2p-ka ah ee jahawareerka ah ee hadda jira

Faahfaahinta:

Muusikasho bada			IEC / EN61009-1
Korato astaamaha	Nooca (Nooca Wave ee Bixinta Bixinta Dhulka ee dareensan)		Nooca elektro-magnetic, nooca elektiroonigga ah
	Lagu qiimeeyay hadda	A	Ac
	Ul shiro	P	2,4
	Korantada lagu qiimeeyay	V	AC 240/415
	Lagu qiimeeyay hadda:		6A, 10,16,20,25,32,40A
	Dareenka la qiimeeyay i △ n	A	0.01,0.03,0.1,0.3,0.5
	Voltage-kulation-ka ui	V	500
	Samaynta haraaga haraaga ah iyo jebinta awooda I △ m	A	630
	Wareeg-gaagaaban i △ c	A	6000
	Fikiska SCPD	A	6000
	Soo noqnoqoshada soo noqnoqda	Dhutaataa ah	50/60
	Shahaadada wasakhda		2
Mashiin ah astaamaha	Nolosha korantada	t	4000
	Nolosha farsamada	t	10000
	Shahaadada Ilaalinta		Ip20
	Heerkulka deegaanka (oo leh celcelis ahaan maalinlaha ah ≤35ºC)	ºC	-25 + 40
	Heerkulka kaydinta	ºC	-25 + 70
Rakaabis	Nooca Xiriirka Terminal		Cable / U-Nooca U-Nooca Busbar / Pin-Nooca Pin-nooca Busbar
	Cabbirka marinka dusha sare / hoose ee fiilada	mm2	25
		W	18-3
	Cabbirka marinka dusha sare / hoose ee baska	mm2	25
		W	18-3
	Adkeysi torque	N*m	2.5
		Gudaha-lbs	22
	Biyo		On tareenka din 60715 (35mm) iyada oo loo adeegsanayo aaladda si dhakhso leh
	Xiriir		Laga bilaabo dusha sare iyo hoose

Bixiyaha 2p

Ilaalinta xad-dhaafka ah

Ilaalinta wareegga gaagaaban

Ilaalinta Bixinta Markuu haraaga hadda ka bato bilowga, Dz30 rcbo-80 RCBO ayaa ka jaban wareegga waqti aad u gaaban si looga hortago shilalka korantada iyo dabka korantada.

Wax soo saarka aragtida:

1. Bixi difaac ka dhan ah ciladaha dhulka / baxsiga hadda jira iyo shaqada go'doominta

2.

3. Waxaa lagu dabaqi karaa Terminal iyo PIN / FOME FR PUNTBAR

4. Ku qalabeysan farta farcanka la ilaaliyo

5. Si otomaatig ah u kala saar wareegga marka ciladaha ciladaha / daadadka uu hadda dhacayo oo uu ka sarreeyo dareenka lagu qiimeeyo

.

Warqad maqas

S 1. Waa maxay ereyga lacag bixinta?

A. Waxaan aqbalnaa TT, 30% dhigaalka iyo 70% isku-dheellitirka Agaisnt ee Agaisnt ee BL

Q 2. Waa sidee waqtiga gudbinta?

A. Badanaa waxay qaadan doontaa 25 maalmood oo wax soo saarka ah

S 3. Ii sheeg heerka xirmada?

J. Caadi ahaan waa kartoonno, laakiin sidoo kale waxaan ku dhejin karnaa sida aad u baahan tahay.

S 4. Waad aqbashaa inaad isticmaasho astaantayada?

A.Haddii aad leedahay tiro wanaagsan, waa wax aan lahayn dhibaato in la sameeyo oem.

Q5. Ma qaadan karaa shaybaar?

A: Haa, waxaan taageernaa inaan qaadno muunado ka hor inta aan amarku saarin. Kaliya waxaad xor u tahay inaad nala soo xiriirto haddii aad wax shuruud ah ku qabtid.

Q6. Ma waxaad tahay warshadda asalka ah?

A: Haa, waxaan leenahay warshadheenna.

Q7. Sideed u hubin kartaa tayada badeecada?

A: Waxaan waashaq siin doonnaa heerarka tayada caalamiga ah ee lagu kormeerayo shay kasta ka hor intaadan ka tagin warshadeena.
